10 Inch 250mm Diamond Grinding Disc with 20 Bar Segments (ED-B20A)

10 Inch 250mm Diamond Grinding Disc with 20 Bar Segments (ED-B20A)

Bond Type Available: soft bond for hard concrete, medium bond for medium concrete, hard bond for soft concrete.

Specifications:

1. Grit available: 6#, 16#, 30/40#, 60/80#, 100/120#, 150#, 200#.

2. Bond Type Available: soft bond, medium bond, hard bond.

A. Extra Soft Bond - For Very Hard Concrete

      B. Soft Bond - For Hard Concrete.  Bonds needs to be soft to expose diamond crystals to grind the hard surface.  Hard  concrete contains hard granite, quartz, river stone, flint rock.

      C. Medium Strength Bond - Suggested in most cases, most popular and most common bond used.  For use on floors containing common pit gravel and/or medium river stone, traprock, crushed gravel.  The Soft and Hard Bonds are typically reserved for extreme (uncommon) cases.

       D. Hard Bond - For Soft Concrete.   Bond has harder metals in its matrix to withstand the abrasion, so the diamond crystals are not kicked-out before they have a chance to work the surface.  Soft concrete contains limestone, sandstone, dolmite, soft shell.

3. Most Consistent, Highest Quality

4. Wet or Dry use


Features:

✅ Model ED-B20A, 10 inch / 250mm diameter, 20 bar diamond segments
✅ Dense 20-bar segments design, smooth, uniform scratch pattern and balanced grinding
✅ Premium metal bond diamond, suitable for soft, medium and hard concrete
✅ Ideal for concrete grinding, surface leveling, epoxy and old coating removal
✅ Supports wet & dry grinding, heavy-duty construction for long working life
